Wienold MFC 750/K Mini Floor Crane
- 2.9m Lifting Height
- 900kg Safe Working Load
- 2 Backwards Outriggers
- Worm Gear Winch
- Adjustable Telescopic Mast
- Precise Handwheel With Auto-Lock
Wienold MFC 750/K Mini Floor Crane
Lift with ease with powerful mini crane
The Wienold MFC 750/K Mini Floor Crane lifts loads up to 900kg to a maximum height hook height of 2.90-metres. With a full extended crane of 1.40-metres, a 410kg payload remains. The mini crane features an extended frame with rear-facing outriggers, which are equipped with one or two boxes each with 14 counterweights. Lowering and raising of the mini floor crane can be precisely controlled via the handwheel which locks automatically when released. The powerful lifting cylinder enables you to lift loads with ease.
Adjustable telescopic mast with high range
The MFC 750/K is a manual crane with telescopic mast, making it perfect for a range of applications in professional sectors. You can adjust the telescope using the 8-fold steps, spaced 14cm apart, measuring from 0.26m to 1.40m of maximum display before the winch wheel. This high range is ideal when obstacles or a limited payload prevents direct access, like on a balcony, or from an open floor. The MFC is also approved for dynamic loads according to DIN 15019-2, EN 13001-1, EN 13001-2.
| Lifting Height Min: | 0.77m |
| Lifting Height Max: | 2.90m |
| Transport Position HxLxW: | 1.00x1.20x0.65m |
| Working Position HxLxW: | 1.92x1.80x0.65m |
| Max Telescopic Extension: | 1.40m |
| Max Payload: | 900kg |
| Base Unit Weight: | 168kg |
| Long Outrigger Weight: | 38kg |
| Lateral Outrigger Weight: | 30kg |
| Weight Box + 14 Weights: | 238kg |
Powerful Lifting Cylinder: Enables you to lift up to 900kg to a hook height of 2.90m.
Extended Frame: With a full extended crane of 1.40m, a 410kg payload remains.
Rear-facing Outriggers: Can be equipped with one or two boxes each with 14 counterweights.
Adjustable Telescopic Mast: Can be adjusted using the 8-fold steps, spaced 0.14cm apart, measuring from 0.26m to 1.40m of maximum display before the winch wheel.
Ergonomically Designed Handwheel: Lowering and raising of the mini floor crane can be precisely controlled via the handwheel which locks automatically when released.
Convenient High Range: The high range is ideal when obstacles or a limited payload prevents direct access, like on a balcony, or from an open floor.
