Ritelite Maxi Cobra High Capacity Rodding Systems
High-quality 11 – 14mm fibreglass rod
Lengths from 250m – 500m
Dimensions W x H x D 1100mm x 1260mm x 700mm
1-year Warranty
Ritelite Maxi Cobra High Capacity Rodding Systems
Ritelite Maxi Cobra High Capacity Rodding Systems are designed to offer a much more robust solution for the demands of larger utility operations. The enhanced, heavy-duty frames still offer the spooling mechanism, with overall dimensions measuring 1100mm x 1260mm x 700mm, which accommodates the high-volume rod storage easily.
The high-end radially reinforced fibreglass rods feature durable protective coatings that are engineered to handle the extra pushing distances without compromising the structural integrity. The range is ideal for long-distance cable pulling, heavier draw-rope threading and large-diameter pipe and duct surveys.
Features & Benefits: Ritelite Maxi Cobra High Capacity Rodding Systems
High-Capacity Storage: Stores extra-long rod lengths from 300m up to 600m.
Sturdy Frame: The zinc-plated steel frames have increased dimensions for the extended rod lengths and maximum stability.
Solid Rods: The High Capacity rods offer a variety of diameters, allowing you to choose from the 11mm or 14mm fibreglass rods.
Industrial Strength: Radially reinforced materials capable of increased complex infrastructure cabling runs.
Extended Cable Length
If you have an operation that requires extreme distance coverage, look no further than the High Capacity rodding range. The increased storage reel capacity eliminates the need for splicing or the need to utilise multiple shorter rods on continuous long-distance duct networks.
Optimal Stability & Support
The increased weight & length of the High Capacity fibreglass rodding range requires a larger, more sturdy frame, which measures at a reassuring 1100mm x 1260mm x 700mm. The larger frame offers enhanced structural support, and the counter-balance ensures that the weight distribution prevents tipping or dragging.
Rod Diameter: 11mm
Length: 400m, 500m
Dimensions W x L x H: 700mm x 1100mm x 1260mm
Pipe Diameter: 80 – 250mm
Breaking Load: 7600kg
Max Bending Radius: 800mm
Rod Diameter: 14mm
Length: 250m, 300m, 350m, 400m, 450m, 500m
Dimensions W x L x H: 700mm x 1100mm x 1260mm
Pipe Diameter: 180 – 450mm
Breaking Load: 20002kg
Max Bending Radius: 1000mm
