Gewiss 32A Interlocked Socket Outlet - Horizontal 250V
- Horizontal interlocked socket outlet
- 2P+E, 32A, 200-250V, 50/60Hz
- IP44 rated, IK08 impact resistance
- Blue, with back-mounting box
- No fuse-holder base
- 6h reference, -25°C to +40°C
Dependable Performance in Demanding Conditions
The Gewiss interlocked socket outlet's thermo-pressure ball rating of 125°C for active parts and 80°C for passive parts ensures consistent performance in high-temperature environments. Its operating temperature range from -25°C to +40°C makes it well-suited for a wide variety of industrial and commercial applications. With a glow wire test rating of 850°C for active parts and 650°C for passive parts, this socket outlet demonstrates exceptional fire resistance and overall safety.
Horizontal Socket Outlet for Secure Power Distribution
Meticulously designed to provide reliable and safe power distribution in industrial and commercial settings, the 32A interlocked socket outlet strictly adheres to the IEC 309 standard. This socket features a mechanical interlock with a circuit breaker, ensuring the plug can only be connected or disconnected when the switch is open. This innovative design significantly enhances safety and minimises the risk of accidental disconnection, providing users with peace of mind.
Durable Construction for Industrial Environments
With an IP44 rating, this 32A socket outlet offers robust protection against solid objects and water splashes, making it an excellent choice for industrial environments. The blue colour coding facilitates quick identification of the voltage rating, even from a distance, instilling confidence in its reliability. The IK08 impact resistance rating demonstrates its ability to withstand mechanical stresses and impacts, ensuring long-lasting durability.
Versatile Integration and Compatibility
Rated for 32A and operating at 200-250V, 50/60Hz, the 2P+E socket outlet is a versatile solution compatible with a wide range of industrial equipment and machinery. The absence of a fuse-holder base streamlines installation and maintenance processes, while the back-mounting box enables seamless integration into various setups, such as boards of the 68 Q-DIN and Q-MC ranges, offering flexibility for power distribution needs.
| TypeHorizontal | Thermo-pressure with ball125 °C (active parts) - 80 °C (passive parts) | IP degreeIP44 | No. of poles2P+E | Mechanical resistanceIK08 | Frequency50/60 Hz | Operating temperature-25 +40 °C | ProtectionNO (SBF) | With back-mounting boxYes | Electrocod2220 | Glow wire test850 °C (active parts) - 650 °C (passive parts) | ColourBlue | Rated current (A)32 | Reference h6 | Rated voltage200-250 V | Ware Number85366990 |
|---|
IK08 impact resistance: This product is designed to withstand mechanical stresses and impacts at an IK08 level, ensuring long-lasting durability.
Wide operating temperature range: Designed to adapt seamlessly to a variety of industrial and commercial environments, providing a reassuring level of versatility
IP44 rating: This product is designed to guard against solid objects larger than 1 mm and water splashes from any direction, making it suitable for most industrial settings.
Blue colour coding: Facilitates quick voltage rating identification from a distance
2P+E, 32A, 200-250V, 50/60Hz: Compatible with a broad range of industrial equipment and machinery
Mechanical interlock with circuit breaker: Enhances safety by preventing accidental disconnection
Back-mounting box: Enables seamless integration into various setups and configurations
